MSP430F5418AIPNR
Texas Instruments
ICPlanet
MSP430 CPUXV2 series Microcontroller IC 16-Bit 25MHz 128KB (128K x 8) FLASH 80-LQFP (12x12)
| Encapsulation: | |
|---|---|
| Quantity: | |
| PDF Export | |
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Embedded - Microcontrollers |
Mfr | Texas Instruments |
Series | MSP430F5xx |
Package | Tape & Reel (TR) Cut Tape (CT) |
Part Status | Active |
Core Processor | MSP430 CPUXV2 |
Core Size | 16-Bit |
Speed | 25MHz |
Connectivity | I²C, IrDA, LINbus, SCI, SPI, UART/USART |
Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
Number of I/O | 67 |
Program Memory Size | 128KB (128K x 8) |
Program Memory Type | FLASH |
EEPROM Size | - |
RAM Size | 16K x 8 |
Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
Data Converters | A/D 16x12b |
Oscillator Type | Internal |
Operating Temperature | -40°C ~ 85°C (TA) |
Mounting Type | Surface Mount |
Package / Case | 80-LQFP |
Supplier Device Package | 80-LQFP (12x12) |
• Low supply voltage range: 3.6 V down to 1.8 V
• Ultra-low power consumption
– Active mode (AM): all system clocks active 230 µA/MHz at 8 MHz, 3.0 V, flash program execution (typical) 110 µA/MHz at 8 MHz, 3.0 V, RAM program execution (typical)
– Standby mode (LPM3): real-time clock (RTC) with crystal, watchdog, and supply supervisor operational, full RAM retention, fast wakeup: 1.7 µA at 2.2 V, 2.1 µA at 3.0 V (typical) low-power oscillator (VLO), general-purpose counter, watchdog, and supply supervisor operational, full RAM retention, fast wakeup: 1.2 µA at 3.0 V (typical)
– Off mode (LPM4): full RAM retention, supply supervisor operational, fast wakeup: 1.2 µA at 3.0 V (typical)
– Shutdown mode (LPM4.5): 0.1 µA at 3.0 V (typical)
• Wake up from standby mode in 3.5 µs (typical)
• 16-bit RISC architecture
– Extended memory
– Up to 25-MHz system clock
• Flexible power-management system
– Fully integrated LDO with programmable regulated core supply voltage
– Supply voltage supervision, monitoring, and brownout
• Unified clock system
– FLL control loop for frequency stabilization
– Low-power low-frequency internal clock source (VLO)
– Low-frequency trimmed internal reference source (REFO)
– 32-kHz crystals
– High-frequency crystals up to 32 MHz
• 16-bit timer TA0, Timer_A with five capture/ compare registers
• 16-bit timer TA1, Timer_A with three capture/ compare registers
• 16-bit timer TB0, Timer_B with seven capture/ compare shadow registers
• Up to four universal serial communication interfaces (USCIs)
– USCI_A0, USCI_A1, USCI_A2, and USCI_A3 each support:
• Enhanced UART supports automatic baudrate detection
• IrDA encoder and decoder
• Synchronous SPI
– USCI_B0, USCI_B1, USCI_B2, and USCI_B3 each support:
• I2C • Synchronous SPI
• 12-bit analog-to-digital converter (ADC)
– Internal reference
– Sample-and-hold
– Autoscan feature
– 14 external channels, 2 internal channels
• Hardware multiplier supports 32-bit operations
• Serial onboard programming, no external programming voltage needed
• 3-channel internal DMA
• Basic timer with RTC feature
• Device Comparison summarizes the available family members 2 Applications
• Analog and Digital Sensor Systems
• Digital Motor Controls
• Remote Controls
• Thermostats
• Digital Timers
• Hand-Held Meters
