MSP430G2553IRHB32R
Texas Instruments
ICPlanet
MSP430 CPU16 series Microcontroller IC 16-Bit 16MHz 16KB (16K x 8) FLASH 32-VQFN (5x5)
| Encapsulation: | |
|---|---|
| Quantity: | |
| PDF Export | |
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Embedded - Microcontrollers |
Mfr | Texas Instruments |
Series | MSP430G2xx |
Package | Tape & Reel (TR) Cut Tape (CT) |
Part Status | Active |
Core Processor | MSP430 CPU16 |
Core Size | 16-Bit |
Speed | 16MHz |
Connectivity | I²C, IrDA, LINbus, SCI, SPI, UART/USART |
Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
Number of I/O | 24 |
Program Memory Size | 16KB (16K x 8) |
Program Memory Type | FLASH |
EEPROM Size | - |
RAM Size | 512 x 8 |
Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
Data Converters | A/D 8x10b |
Oscillator Type | Internal |
Operating Temperature | -40°C ~ 85°C (TA) |
Mounting Type | Surface Mount |
Package / Case | 32-VFQFN Exposed Pad |
Supplier Device Package | 32-VQFN (5x5) |
FEATURES
• Low Supply-Voltage Range: 1.8 V to 3.6 V
• Universal Serial Communication Interface (USCI)
• Ultra-Low Power Consumption
– Active Mode: 230 µA at 1 MHz, 2.2 V
– Enhanced UART Supporting Auto Baudrate Detection (LIN)
– Standby Mode: 0.5 µA
– IrDA Encoder and Decoder
– Off Mode (RAM Retention): 0.1 µA
– Synchronous SPI
• Five Power-Saving Modes
– I 2
• Ultra-Fast Wake-Up From Standby Mode in C™ Less Than 1 µs
• On-Chip Comparator for Analog Signal Compare Function or Slope Analog-to-Digital
• 16-Bit RISC Architecture, 62.5-ns Instruction (A/D) Conversion Cycle Time
• 10-Bit 200-ksps Analog-to-Digital (A/D)
• Basic Clock Module Configurations Converter With Internal Reference, Sample-
– Internal Frequencies up to 16 MHz With and-Hold, and Autoscan Four Calibrated Frequency
• Brownout Detector
– Internal Very-Low-Power Low-Frequency
• Serial Onboard Programming, (LF) Oscillator No External Programming Voltage Needed,
– 32-kHz Crystal Programmable Code Protection by Security
– External Digital Clock Source Fuse
• Two 16-Bit Timer_A With Three
• On-Chip Emulation Logic With Spy-Bi-Wire Capture/Compare Registers Interface
• Up to 24 Capacitive-Touch Enabled I/O Pins
• Family Members are Summarized
• Package Options
– TSSOP: 20 Pin, 28 Pin
– PDIP: 20 Pin
– QFN: 32 Pin
• For Complete Module Descriptions, See the MSP430x2xx Family User’s Guide
