MAX313LEUE+-ND
Analog Devices Inc./Maxim Integrated
MAX313LEUE+-ND
Analog Devices Inc./Maxim Integrated
Tube
Yes
500000
| Quantity: | |
|---|---|
| PDF Export | |
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Interface Analog Switches, Multiplexers, Demultiplexers |
Mfr | Analog Devices Inc./Maxim Integrated |
Series | - |
Package | Tube |
Product Status | Active |
Switch Circuit | SPST - NO |
Multiplexer/Demultiplexer Circuit | 1:1 |
Number of Circuits | 4 |
On-State Resistance (Max) | 10Ohm |
Channel-to-Channel Matching (ΔRon) | 300mOhm |
Voltage - Supply, Single (V+) | 4.5V ~ 36V |
Voltage - Supply, Dual (V±) | ±4.5V ~ 20V |
Switch Time (Ton, Toff) (Max) | 225ns, 185ns |
-3db Bandwidth | - |
Charge Injection | 20pC |
Channel Capacitance (CS(off), CD(off)) | 15pF, 15pF |
Current - Leakage (IS(off)) (Max) | 500pA |
Crosstalk | -85dB @ 1MHz |
Operating Temperature | -40°C ~ 85°C (TA) |
Mounting Type | Surface Mount |
Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
Supplier Device Package | 16-TSSOP |
Base Product Number | MAX313 |
