MAX1685EEE+-ND
Analog Devices Inc./Maxim Integrated
MAX1685EEE+-ND
Analog Devices Inc./Maxim Integrated
Tube
Yes
95310
| Quantity: | |
|---|---|
| PDF Export | |
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Power Management (PMIC) Voltage Regulators - DC DC Switching Regulators |
Mfr | Analog Devices Inc./Maxim Integrated |
Series | - |
Package | Tube |
Product Status | Active |
Function | Step-Down |
Output Configuration | Positive |
Topology | Buck |
Output Type | Adjustable (Fixed) |
Number of Outputs | 1 |
Voltage - Input (Min) | 2.7V |
Voltage - Input (Max) | 14V |
Voltage - Output (Min/Fixed) | 1.25V (3.3V) |
Voltage - Output (Max) | 14V |
Current - Output | 1A |
Frequency - Switching | 600kHz |
Synchronous Rectifier | Yes |
Operating Temperature | -40°C ~ 85°C (TA) |
Mounting Type | Surface Mount |
Package / Case | 16-SSOP (0.154", 3.90mm Width) |
Supplier Device Package | 16-QSOP |
Base Product Number | MAX1685 |
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Power Management (PMIC) Voltage Regulators - DC DC Switching Regulators |
Mfr | Analog Devices Inc./Maxim Integrated |
Series | - |
Package | Tube |
Product Status | Active |
Function | Step-Down |
Output Configuration | Positive |
Topology | Buck |
Output Type | Adjustable (Fixed) |
Number of Outputs | 1 |
Voltage - Input (Min) | 2.7V |
Voltage - Input (Max) | 14V |
Voltage - Output (Min/Fixed) | 1.25V (3.3V) |
Voltage - Output (Max) | 14V |
Current - Output | 1A |
Frequency - Switching | 600kHz |
Synchronous Rectifier | Yes |
Operating Temperature | -40°C ~ 85°C (TA) |
Mounting Type | Surface Mount |
Package / Case | 16-SSOP (0.154", 3.90mm Width) |
Supplier Device Package | 16-QSOP |
Base Product Number | MAX1685 |
