LM536003QDSXRQ1
Texas Instruments
LM536003QDSXRQ1
Texas Instruments
Tape & Reel (TR)
Yes
30000
| Quantity: | |
|---|---|
| PDF Export | |
TYPE | DESCRIPTION |
|---|---|
Category | Integrated Circuits (ICs) Power Management (PMIC) Voltage Regulators - DC DC Switching Regulators |
Mfr | Texas Instruments |
Series | Automotive, AEC-Q100 |
Package | Tape & Reel (TR) |
Product Status | Active |
Function | Step-Down |
Output Configuration | Positive |
Topology | Buck |
Output Type | Fixed |
Number of Outputs | 1 |
Voltage - Input (Min) | 3.8V |
Voltage - Input (Max) | 36V |
Voltage - Output (Min/Fixed) | 3.3V |
Voltage - Output (Max) | - |
Current - Output | 650mA |
Frequency - Switching | 2.1MHz |
Synchronous Rectifier | Yes |
Operating Temperature | -40°C ~ 150°C (TJ) |
Mounting Type | Surface Mount |
Package / Case | 10-WFDFN Exposed Pad |
Supplier Device Package | 10-WSON (3x3) |
Base Product Number | LM536003 |
