| IC CPLD 980MC 6.2NS 144TQFP |
EPM1270T144C5N
Intel
Intel
Customer Reference
| Quantity: | |
|---|---|
| PDF Export | |
Product Attributes
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded - CPLDs (Complex Programmable Logic Devices) | |
| Mfr | Intel |
| Series | MAX® II |
| Package | Tray |
| Part Status | Active |
| Programmable Type | In System Programmable |
| Delay Time tpd(1) Max | 6.2 ns |
| Voltage Supply - Internal | 2.5V, 3.3V |
| Number of Logic Elements/Blocks | 1270 |
| Number of Macrocells | 980 |
| Number of I/O | 116 |
| Operating Temperature | 0°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 144-LQFP |
| Supplier Device Package | 144-TQFP (20x20) |
